High-performance 14-bit, 1.6 GSPS digitizer
The ADQ1600TD is a world-leading 14 bit digitizer optimized for time-domain pulse capture. With its unique 1600 MSPS capture rate, enabled by SP Devices’ ADC interleaving technology ADX, the ADQ1600TD opens for demanding measurements such as time-domain pulse capture and high-speed data recording.
The AFE of the ADQ1600TD is AC-coupled and optimized for low background noise over a large bandwidth. The adjustable bias together with the Digital Baseline Stabilization (DBS) technology increases the dynamic range for unipolar pulses.
The digitizer connects to the host via a high-speed USB 3.0 cable for easy-to-use standalone operation. PXI Express or MTCA.4 µTCA interface is available for systems integration as a modular instrument. A PCIe version for integration into a PC is also available. All interface types allows for streaming of data at high transfer rates.
Ordering Information
| Options | Comment |
| Hardware Options | |
| USB 3.0, PXIe, PCIe, Micro-TCA | Host PC interface |
Firmware options | |
| FWDAQ | Always included. Default data acquisition firmware. |
| DEVDAQ | Optional FPGA development kit based on FWDAQ. |
Additional accessories | |
| W5Y | Optional 2-year warranty extension (and 5 years in total). |
Software | |
| ADCaptureLab | Always included. Software for control and configuration. |
